SN 15-45A

Home /  Products /  GEN Single Pole Power Connectors /  SN 15-45A

High Quality Anderson PP style 15a/30a/75a/120a 600v High Current Power Battery Terminal Connector for Forklift Drone Car

Product Description
Rated current(Amperes) 15-45A
Voltage Ratings(Volts) 600V
Contact Barrel Wire Size[AWG]mm

20-10AWG

0.75-5.3mm

Maximum Wire Insulation Diameter[inches]mm

0.175inches

4.45mm

AVG Contact Resistance(micro-ohms) <500
Insulation Withstanding Test Voltage(Volts AC/DC) 2200V
Contact Retention Force(lbf) 25lbf

Life

a.No load (Contact/Disconnect Cycles)

b.under Load (Hot Plug 250 cycles @120V)

To 10,000

15-30A

AVg.Connection/Disconnect (lbf) 3-5lbf
operating Temperature Range℃ ℉

-20"to 105°

-4"to 221"

Flammability Rating of Housing Material UL 94-V0
Contact Material Silver plated copper

 Introducing, the High Quality Anderson PP style High Current Power Battery Terminal Connector! Whether you need a reliable power source for your forklift, drone, car, or any other vehicle, this connector is designed to deliver top-of-the-line performance. Made with durable materials and precision engineering, this connector can handle up to 600 volts of power, making it perfect for high current applications. With options ranging from 15a to 120a, you can choose the connector that best suits your power needs. The Anderson PP style design ensures a secure and stable connection, giving you peace of mind knowing that your power source is reliable and safe. The easy-to-use plug and play design makes installation a breeze, saving you time and effort. Whether you are a professional mechanic or a DIY enthusiast, this connector is designed to meet your needs. The high quality construction ensures longevity and durability, so you can rely on it for years to come. Equipped with high performance and versatility, the High Quality Anderson PP style High Current Power Battery Terminal Connector is the perfect choice for all your power needs. Don't settle for inferior connectors that can't handle the demands of your vehicle - choose the best with. Upgrade your power source today with the High Quality Anderson PP style High Current Power Battery Terminal Connector. Experience the difference in performance and reliability that only can provide. Order yours now and take your vehicle to the next level

High Quality Anderson PP style 15a/30a/75a/120a 600v High Current Power Battery Terminal Connector for Forklift Drone Car manufacture
Our advantage
High Quality Anderson PP style 15a/30a/75a/120a 600v High Current Power Battery Terminal Connector for Forklift Drone Car supplier
1. The model, color and anderson pp series are completely common
----------------------------
----------------------------
3. We do not discount the materials we use, welcome to compare
----------------------------
4. All models are complete, one-stop purchasing can be realized
High Quality Anderson PP style 15a/30a/75a/120a 600v High Current Power Battery Terminal Connector for Forklift Drone Car factory
Parameter introduction
Contact barrel wire size
20-10AWG 0.75-5.3mm²
Application
Electric vehicles;Medical equipment;Power supply;Electric equipment;
MQQ
100
Maximum wire insulation diameter
0.175inches 4.45mm
Insulation withstanding test voltage
2200v
Contact retention force
25lbf
Avg.connection/disconnect
3-5ibf
Operating temperature range
-20°to105°
-4°to221°
Flammability rating of housing material
UL94-VO
High Quality Anderson PP style 15a/30a/75a/120a 600v High Current Power Battery Terminal Connector for Forklift Drone Car details
High Quality Anderson PP style 15a/30a/75a/120a 600v High Current Power Battery Terminal Connector for Forklift Drone Car manufacture
High Quality Anderson PP style 15a/30a/75a/120a 600v High Current Power Battery Terminal Connector for Forklift Drone Car manufacture
High Quality Anderson PP style 15a/30a/75a/120a 600v High Current Power Battery Terminal Connector for Forklift Drone Car supplier
High Quality Anderson PP style 15a/30a/75a/120a 600v High Current Power Battery Terminal Connector for Forklift Drone Car supplier
High Quality Anderson PP style 15a/30a/75a/120a 600v High Current Power Battery Terminal Connector for Forklift Drone Car supplier
High Quality Anderson PP style 15a/30a/75a/120a 600v High Current Power Battery Terminal Connector for Forklift Drone Car details
High Quality Anderson PP style 15a/30a/75a/120a 600v High Current Power Battery Terminal Connector for Forklift Drone Car details
High Quality Anderson PP style 15a/30a/75a/120a 600v High Current Power Battery Terminal Connector for Forklift Drone Car supplier
High Quality Anderson PP style 15a/30a/75a/120a 600v High Current Power Battery Terminal Connector for Forklift Drone Car factory
