| Rated current(Amperes) | 350A |
| Voltage Ratings(Volts) | 600V |
| Contact Barrel Wire Size[AWG]mm |
2/0 to 300mcm 67.4to 152mm |
| Maximum Wire Insulation Diameter[inches]mm |
1.1inches 27.9mm |
| AVG Contact Resistance(micro-ohms) | 50 |
| Insulation Withstanding Test Voltage(Volts AC/DC) | 2200V |
| Contact Retention Force(lbf) | 500lbf |
|
Life a.No load (Contact/Disconnect Cycles) b.under Load (Hot Plug 250 cycles @120V) |
To 10,000 100A |
| AVg.Connection/Disconnect (lbf) | 30lbf |
| operating Temperature Range℃ ℉ |
-20 "to 105" -4 "to 221" |
| Flammability Rating of Housing Material | UL 94-V0 |
| Contact Material | Silver plated copper |
Introducing, the Power Pole 350A Forklift Connector, the ultimate high-power vehicle connectivity solution for all your industrial needs. This innovative product is designed to provide seamless and reliable power transfer for forklifts and other heavy-duty vehicles, making it a must-have accessory for any warehouse or manufacturing facility.
With a 350A rating, the Power Pole Connector is capable of handling even the most demanding power requirements, ensuring that your equipment always stays up and running. Its durable construction and high-quality materials make it a long-lasting and dependable solution for all your power needs.
One of the key features of the Power Pole Connector is its easy and convenient installation process. Simply attach the connector to your vehicle and power source, and you're ready to go. No complicated wiring or setup required – just plug and play.
In addition to its power and convenience, the Power Pole Connector also offers unmatched safety features. The connector is designed to prevent any electrical shorts or sparks, keeping your equipment and operators safe at all times. Its rugged design can withstand even the harshest working conditions, ensuring that it will stand the test of time.
Whether you're operating a large warehouse or a busy manufacturing facility, the Power Pole 350A Forklift Connector is the perfect solution for all your power needs. Say goodbye to unreliable and inefficient power connections – with the Power Pole Connector, you can trust that your equipment will always have the power it needs to get the job done.
Invest in the Power Pole 350A Forklift Connector today and experience the difference it can make in your operations. With its high-power capabilities, easy installation, and unmatched safety features, this product is sure to become an essential part of your industrial equipment arsenal. Order yours now and see the difference that the Power Pole Connector can make for your business.
350A power pole forklift connector
Product Description
| Application | Electric vehicles; Medical equipment;Power supply; Electric equipment; |
| Maximum wire insulation diameter | 1.1inches 27.9mm |
| Insulation withstanding test voltage | 2200v |
| Contact retention force | 500lbf |
| Avg. connection/disconnect | 30lbf |
| Operating temperature range |
-20°to105° -4°to221° |
| Flammability rating of housing material | UL94-VO |
